R3T-01: 1kg Payload Industrial Robot

R3T-01: 1kg Payload Industrial Robot

The R3T-01 robot provides a cost-effective solution, innovative configuration and technologies, rapid and flexible response to the emerging need about the automation of the core industrial application. This robot improves productivity, quality and uniformity of products, reduce the risk of labor accidents.

Specifications:

• Robot Model: R3T-01 Industrial Robot
• Degree of freedom: 4 DOFs
• Payload: 1 kg
• Reach: 850mm
• Speed: 180 degree/s for all joints, tool: 1100mm/s
• Repeatability : +/- 0.05mm
• Communication: Modbus TCP/IP
• Programing: Graphic User Interface ( 11.6 inch Tech Pendant)
• Materials: Aluminum AL6061 & Anodized
• Weight: 25kg
• Teaching:  Ponit-to-Point
• Importing Gcode files.
• Temperature: 0 – 50 degree C
• Power: 200 to 240VAC, 50-60Hz

Parameters of the teaching appratus

• Size: 350 x 210 x 40 mm
• Weight: 1600 gram
• Display: 11.6 inch capacitive LCD
• Connecting line length: 3.5m
• Protection Level: ỊP54

Parameters of the control box

• Size: 500 x 500 x 500 mm
• Weight: 30kg
• Color: White
• AC Servo Driver: 4 units
• I/O Port: Digital Input and Output: 24, Analog Input and Output: 8
• Connection Robot and Connection Control Box Wire: 6m
